VCM-1100F
Intel® Core™ 200S Series and 14/13/12th Gen Intel® Core™ Processor, Compact Embedded Computing System, 6 GigE LAN with 4 PoE+, 12 USB, 28 Isolated DIO, DC 24V, High Performance, Compact, -25°C to 75°C Extended Temperature
Features:
- Intel® Core™ 200S Series and 14/13/12th Gen Intel® Core™ Processor (codename: Bartlett Lake-S/Raptor Lake-S Refresh/Raptor Lake-S/Alder Lake-S) running with Intel® H610E PCH
- Intel® Core™ 200S Series with P-core only available (codename: Bartlett Lake 12P)
- 2 DDR5 5200MHz SO-DIMM, up to 96GB Memory
- 6 Independent GigE LAN with 4 IEEE 802.3at PoE+
- 12 USB, 2 COM RS-232/422/485, 28 Isolated DIO
- WiFi/4G/3G/LTE/GPRS/UMTS, M.2 Key E, M.2 Key B
- Software Ignition Control, TPM 2.0, Intel® TCC, Wake on LAN, PXE
- Compact 2U half-rack design, -25°C to 75°C wide range operating temperature
- Optional VHub AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications
