RCX-1400FR PEG
Workstation-grade 9th/8th Gen Intel® Xeon®/Core™ i7/i5/i3 processor (Coffee Lake) Expandable GPU Computing System with Intel® C246 & NVIDIA® Tesla®/Quadro®/GeForce® graphics, NVIDIA Turing/Pascal architecture, 7 displays, 8K resolution, 2 GigE LAN, 6 10G USB 3.1 Gen 2, 4 COM RS-232/422/485, 2 SIM, 4 Front-access 2.5" SSD/HDD Tray, 2 PCI/PCIe Slot, M.2, 32 Isolated DIO, High Performance, Flexible, Expandable
Features:
- 8 Cores 9th/8th Gen Intel® Xeon®/Core™ i7/i5/i3 (Coffee Lake) with Workstation-grade Intel® C246 chipset
- 4 DDR4 2666MHz memory, up tp 128GB (ECC/Non-ECC)
- 6 External USB 3.1 Gen 2 support up to 10Gbps data transfer
- Supports up to 300W NVIDIA® or AMD Graphics card
- NVIDIA® Tesla®/Quadro®/GeForce® graphics card, powered by advanced NVIDIA Turing/Pascal architecture, delivers leading AI computing productivity
- Multiple DVI, HDMI and DisplayPort display interfaces support max 7 independent displays, up to 8K resolution
- 2 Independent GigE LAN iAMT 12.0 supported
- 2 External SIM socket for WiFi/4G/3G/LTE/GPRS/UMTS
- 4 Front-access 2.5" SSD trays, RAID 0, 1, 5, 10 supported
- 32 Isolated DIO, 4 COM RS-232/422/485
- 2 PCI/PCIe Slot, 2 M.2 Socket：1 M.2 Key M, 1 M.2 Key E
- System-oriented power consumption, up to 300W independent graphics card
- Supports wide range power input with 80V Surge Protection
- Configurable Ignition Power Control
