Icubes Industrial

P1001 Series

Intel® Atom™ E3845 Quad Core PC Module, 4x USB, 2x COM, 1x VGA and 1x DisplayPort

Features:

Onboard Intel® Atom™ E3845 Processor Quad Core, 1.91GHz
1x DDR3L SO-DIMM max. up to 8GB
1x 2.5” SATA HDD bay, 1x CFast Card and 1x SIM Card Socket
2x LAN, 4x USB, 2x COM, 1x VGA, 1x DisplayPort
4x Isolated DI, 4x Isolated DO
Wide Range Power Input 9~48VDC
1x Mini-PCIe Expansion Socket
Support Wall / VESA / CDS Mounting
Convertible Display System (CDS) Supported
Built-in Two 2W Internal Speakers

Overview

Powered by Intel® Atom™ E3845 Quad Core 1.91GHz , P1001 Series is the fanless PC module. It supports Convertible Display System (CDS) technology which allow to be used for configuring, upgrading and maintaining your Convertible Panel PC. P1001 Series offers extensive I/O including 4x USB, 2x RS232/422/485, 1x VGA, 1x DisplayPort and 4 DI/ 4DO. In addition, it supports GSM and WLAN via 2x GbE and 1x Mini-PCIe slot. Furthermore, P1001 Series supports 3 types of storage devices including 2.5" SATA HDD, CFast and SIM card. The accessible design of these storage devices allows quick data access and easy maintenance. It supports wide range DC power input from 9~48 VDC. P1001 Series is an ideal solution for configuring your Convertible Panel PC. Furthermore, it is a great fanless computer for various industrial applications.
