IVX-1000
Intel® Core™ 200S Series and 14/13/12th Gen Intel® Core™ Processor In-Vehicle Computing Workstation, 16V to 160V DC Power Input with 4kV DC Isolation, up to 500V Surge Protection, 8 Independent 2.5GigE LAN M12 X-coded with 4 IEEE 802.3at PoE+, 1 2.5GigE LAN, 1 GigE LAN, 4 Isolated COM, 2 Front-access 2.5"SSD/HDD Tray
Features:
- Workstation-grade Platform : Intel® Core™ 200S Series and 14/13/12th Gen Intel® Core™ Processor (codename: Bartlett Lake-S/Raptor Lake-S Refresh/Raptor Lake-S/Alder Lake-S) running with Intel® R680E PCH supports max 65W TDP CPU
- Intel® Core™ 200S Series with P-core only available (codename: Bartlett Lake 12P)
- Optional supports outstanding AI computing productivity by advanced and compact NVIDIA® Quadro® MXM graphics
- 16V to 160V DC Power Input with 4kV DC Isolation, up to 500V Surge Protection, Software Ignition Power Control, optional UPS supported
- Fanless design for railway in-vehicle applications, fully compliant with EN50155:2021
- 8 Independent 2.5GigE LAN M12 X-coded with 4 IEEE 802.3at PoE+, 1 2.5GigE LAN, 1 GigE LAN, 4 Isolated COM
- 2 Front-access 2.5"SSD/HDD Tray, multiple 5G/WiFi/4G/3G/LTE/GPRS/UMTS
- Supports Intel® vPro, TCC, Time-Sensitive Networking (TSN), and TPM 2.0
- Optional VHub AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications
