NVIDIA Jetson AGX Orin Developer Kit
Industrial IoT Controller
Features:
- NVIDIA Jetson AGX Orin Industrial (JAOi) SOM support, up to 248 TOPs (INT8)
- NVIDIA Jetson AGX Orin 64GB (JAO 64GB) SOM support, up to 275 TOPs (INT8)
- NVIDIA Jetson AGX Orin 32GB (JAO 32GB) SOM support, up to 200 TOPs (INT8)
- Wide Range Operating Temperature (-10°C to 45°C for WO/PoE SKU) (-10°C to 35°C for W/PoE SKU)
- 12-48V Phoenix type DC IN support
- Carrier board MIPI 120-pin connector support up to 4 × 4 lane MIPI cameras or up to 4 × 4 lane GMSLII cameras via FARKA connectors
- 2 x PCIe Gen4 x8 signal on 2 x PCIe x16 Connectors
- 1 x M.2 Key M 2280 (PCIe Gen4x4) and 1x Micro SD card for Storage
- 1 x M.2 Key B 3042/3052 (USB3.2 Gen2/ USB2.0 x1 / PCIe Gen3x1) w/Nano SIM Socket for 4G LTE, 5G or POE
- 1 x M.2 Key E Type 2230/2260 (PCIe Gen3x1 + USB2.0) for Wifi/BT or POE, PCIe signal share with LAN2 I226IT
- Up to 12*POE support via M.2 E Key and B Key module, and PCIE-2.5GPoE-4P add on cards. (each port supports up to IEEE 802.3af based on 12V~36V)
- 1 x SPEAKER-OUT-L/R Wafer with 2W/2W design and 1 x MIC IN
- 1 x 40 pin expansion header for I2S/I2C/SPI/UART/CAN/PWM/GPIO
