DSF-A6000

Fanned Embedded BOX PC

Features:

• AMD Ryzen™ Embedded R-Series R2314
• 2 x 260-pin ECC/non-ECC SO-DIMM DDR4 2666 MHz, up to 64GB (32GB per DIMM)
• 2 x USB 3.2 Gen2, 1 x USB 2.0, 1 x M.2 Key B, 1 x M.2 Key E, 1 x M.2 Key M, 1 x COM
• 1 x Intel Gigabit LAN, 1 x Realtek Gigabit LAN,1 x Realtek 2.5 Gigabit LAN with PoE+ function (optional)
• Support Quad display, 4 x HDMI 2.0b
• TPM 2.0 onboard IC
• Optional support 24/7 Edge AI device remote management through MPU-OOB card
• 1 x 19V/90W power adapter
• 182.2 x 175.2 x 25mm ( 7.1" x 6.9" x 1"), Fanned Barebone
